• Paint, solid
• Body, standard
• Upfitter Package
• Trim, rear body-colored halo (replaces standard black panel - the panel is located above rear tail lamps). (Not available with (74U) Fire Red or (41U) Onyx Black. These two colors will receive a molded in color, black halo.)
• Bumper, front, chrome
• Grille, chrome
• Headlamps, dual composite halogen
• Daytime running lamps
• Mirrors, outside rearview, manual folding, power adjust, heated, Black
• Glass, Solar-Ray deep tinted (all windows except light tinted glass on windshield, driver and front passenger)
• Glass, rear door window, swing-out
• Glass, rear side door and rear door window, swing-out
• Glass, rear doors and side cargo doors
• License plate bracket, front
• Wipers, intermittent, front wet-arm with pulse washers
• Door, swing-out passenger side, 60/40 split

• Seat, temporary driver, includes driver and passenger side safety belts and seat risers
• Floor covering delete
• Oil life monitor
• Warning tones, headlamp on
• Convenience Package, Tilt-Wheel and cruise control
• Convenience Package, power windows and door locks
• Tow/haul mode selector, IP mounted
• Theft-deterrent system, PASSLock
• Air conditioning, front manual (Includes quick connectors for rear air conditioning.)
• Sound system, ETR AM/FM stereo with CD player, includes seek-and-scan, digital clock, TheftLock and random select (Not available with (UE1) OnStar.)
• Console, deluxe, includes glove box
• Trim panels, front, side and rear doors
• Mirror, inside rearview, electrochromic (light-sensitive auto dimming), compass and outside temperature indicator (Not available with (UE1) OnStar.)
• Visors, padded, driver and passenger side with cloth trim and dual vanity mirrors, illuminated on passenger side
• Assist handle, front passenger

• Brakes, 4-wheel antilock, 4-wheel disc
• Air bags, frontal, driver and right front passenger (Includes passenger side air bag deactivation switch on models with (C6P) GVWR, 8600 lbs. (3901 kg) and above. Always use safety belts and proper child restraints, even with air bags. Children are safer when properly secured in a rear seat. See the Owner's Manual for more safety information.)
• Door beams, steel-side
• Daytime running lamps

ENGINE, VORTEC 5300 V8 SFI

• (285 HP [212.6 kW] @ 5200 rpm
• 325 lb.-ft. [445.5 N-m] @ 4000 rpm) (STD)

• Full Body Fixed Glass Window Package
• Heavy-Duty Trailering Equipment
• AM/FM radio
• Air Conditioning
• Front Manual Air Conditioning
• Power steering
• Remote Keyless Entry
• 4-Wheel Disc Brakes
• ABS brakes
• Dual front impact airbags
• Front anti-roll bar
• Front wheel independent suspension
• 800 CCA Heavy-Duty Battery
• Standard Body
• 60/40 Split Swing-Out Driver Side Door
• Heavy-Duty Rear Locking Differential
• 145 Amp Alternator
• Black Power Adjust Heated Outside Rear-View Mirrors
• Front License Plate Bracket
• Rear Body-Colored Halo Trim
• 8-Point Compass & Outside Temperature Indicator
• Deluxe Console
• Driver door bin
• Electrochromic Inside Rear-View Mirror
• Voltmeter
• Custom Vinyl Seat Trim
• Passenger door bin
• 7-Lead Trailer Wiring Harness
• Gray Painted w/Chrome Center Caps Wheels
• Solar-Ray Deep Tinted Glass
• Swing-Out Rear & Side Door Window Glass
• Variably intermittent wipers

• Vehicle
• Rear Door Type: Dual Swing-out
• Electrical
• Cold Cranking Amps @ 0° F (Primary): 800
• Maximum Alternator Capacity (amps): 145
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): 14.4
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3600
• Gross Axle Wt Rating - Rear (lbs): 4000
• Curb Weight - Front (lbs): 2915.7
• Curb Weight - Rear (lbs): 2106.7
• Gross Vehicle Weight Rating Cap (lbs): 7200
• Gross Combined Wt Rating (lbs): 12000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 6600
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 660
• Suspension
• Suspension Type - Front: Torsion Bar
• Suspension Type - Rear: Hypoid Multi-Leaf
• Spring Capacity - Front (lbs): 3600
• Spring Capacity - Rear (lbs): 4000
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3600
• Axle Capacity - Rear (lbs): 4000
• Axle Ratio (:1) - Front: 3.42
• Axle Ratio (:1) - Rear: 3.42
• Shock Absorber Diameter - Front (mm): - TBD -
• Shock Absorber Diameter - Rear (mm): - TBD -
• Stabilizer Bar Diameter - Front (in): 1.30
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12 x 1.14
• Rear Brake Rotor Diam x Thickness (in): 13 x 1.18
• Tires
• Front Tire Order Code: XEN
• Rear Tire Order Code: XEN
• Spare Tire Order Code: XEN
• Front Tire Size: P235/75R16EL
• Rear Tire Size: P235/75R16EL
• Spare Tire Size: P235/75R16
• Front Tire Capacity (lbs): 1903
• Rear Tire Capacity (lbs): 2004
• Spare Tire Capacity (lbs): 2004
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 16 x - TBD -
• Rear Wheel Size (in): 16 x - TBD -
• Spare Wheel Size (in): 16 x - TBD -
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr-Assisted
• Steering Ratio (:1), On Center: 17.2
• Steering Ratio (:1), At Lock: 17.2
• Turning Diameter - Curb to Curb (ft): 43.4
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 31
• Fuel Tank Location: LH Midship Inboard
• Doors
• Side Door Type: Swing-out
• Exterior Dimensions
• Wheelbase (in): 135
• Length, Overall w/rear bumper (in): 224.1
• Width, Max w/o mirrors (in): 79.4
• Height, Overall (in): 81.6
• Overhang, Front (in): - TBD -
• Overhang, Rear w/bumper (in): - TBD -
• Ground to Top of Load Floor (in): 27.7
• Ground Clearance, Front (in): 8.6
• Ground Clearance, Rear (in): 7.6
• Rear Door Opening Height (in): 49.4
• Rear Door Opening Width (in): 57.0
• Side Door Opening Height (in): 47.9
• Side Door Opening Width (in): 44.1
• Step Up Height - Front (in): 20.1
• Step Up Height - Side (in): 20.9
• Cargo Area Dimensions
• Cargo Area Length @ Floor to Console (in): 153.6
• Cargo Area Length @ Floor to Seat 1 (in): 127.8
• Cargo Area Width @ Beltline (in): - TBD -
• Cargo Box Width @ Wheelhousings (in): 52.7
• Cargo Box (Area) Height (in): 51.9
• Cargo Volume (ft³): 225.1
• Interior Dimensions
• Passenger Capacity: 1
• Front Head Room (in): 40.2
• Front Leg Room (in): 41.3
• Front Shoulder Room (in): 68.8
• Front Hip Room (in): 65.5
• Summary
• Vehicle Name: GMC Savana Cargo Van
• Body Style: 1500 Cargo Van 135" WB w/YF7
• Body Code: ZW9
